Trinity Panels elevate the light in your classrooms, offices, and retail spaces with a unique direct/indirect design for soft, low-glare illumination (UGR19). It prioritise safety by offering TP(a) fire escape route suitability, 850-degree glow wire test approval, and optional self-testing emergency lighting. Energy Class B rating, PIR occupancy sensors (sold separately), and wattage switchability (13W to 25W) all help to optimise energy use. Trinity Panels offer DALI-2 or PUSH-DIM driver options, as well as a variety of mounting styles, making them the ideal combination of adaptability, efficiency (up to 156 Lm/W), and style.
| Code | CRI | UGR | IP Rating | Beam Angle | Wattage Range | CCT Range | Lumens Range | Sensor Option | Dimmable Option | Emergency Option | Body Material | Colour / Finish | Mounting Type | Width | Length | Base Shape | Downloads |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TRI66N40 | CRI>80 | 19 | IP20 | 80° | 13-16-18-20-26W | 4000K | 1900-2500-2800-3100-3700 | DALI|On-Off|PIR|Step-Dim | DALI-2|PUSH-DIM | Manual-Test|Self-Test|DALI-2 | Steel | White | Ceiling | 595 | 595 | Square | |
| TRI66X40 | CRI>80 | 19 | IP20 | 80° | 13-16-18-20-26W | 4000K | 1900-2500-2700-3100-3900 | DALI|On-Off|PIR|Step-Dim | DALI-2|PUSH-DIM | Manual-Test|Self-Test|DALI-2 | Steel | White | Ceiling | 595 | 595 | Square |
