UL030

Switchable driver option for quick and easy installion
Coastal protected
IP68 ideal for outdoor areas and under water lighting
Single LED and lens combination for maximum efficiency and optimal light distribution
Complete with wall fixings
Tilt & rotate for adjusting light
Available in an array of colours
Long lifetime of 70,000hrs

Beam Angle

CCT Range

Colour / Finish

Wattage / Lumens

Code	CRI	IP Rating	Adjustability	Beam Angle	Wattage Range	CCT Range	Lumens Range	Colour / Finish	Dimmable Option	Body Material	Width	Length	Sensor Option
UL030SS27XS	CRI>80	IP68	Rotating and swivelling	12°	0.85W / 1.4W / 2W / 3W / 4.6W	2700K	129 - 515	Stainless Steel	None	Stainless Steel 316	65	65	None
UL030SS30XS	CRI>80	IP68	Rotating and swivelling	12°	0.85W / 1.4W / 2W / 3W / 4.6W	3000K	130 - 520	Stainless Steel	None	Stainless Steel 316	65	65	None
UL030SS40XS	CRI>80	IP68	Rotating and swivelling	12°	0.85W / 1.4W / 2W / 3W / 4.6W	4000K	134 - 538	Stainless Steel	None	Stainless Steel 316	65	65	None
UL030SS27XF	CRI>80	IP68	Rotating and swivelling	40°	0.85W / 1.4W / 2W / 3W / 4.6W	2700K	129 - 515	Stainless Steel	None	Stainless Steel 316	65	65	None
UL030SS30XF	CRI>80	IP68	Rotating and swivelling	40°	0.85W / 1.4W / 2W / 3W / 4.6W	3000K	130 - 520	Stainless Steel	None	Stainless Steel 316	65	65	None
UL030SS40XF	CRI>80	IP68	Rotating and swivelling	40°	0.85W / 1.4W / 2W / 3W / 4.6W	4000K	134 - 538	Stainless Steel	None	Stainless Steel 316	65	65	None
UL030AB27XS	CRI>80	IP68	Rotating and swivelling	12°	0.85W / 1.4W / 2W / 3W / 4.6W	2700K	129 - 515	Antique brass	None	Brass	65	65	None
UL030AB30XS	CRI>80	IP68	Rotating and swivelling	12°	0.85W / 1.4W / 2W / 3W / 4.6W	3000K	130 - 520	Antique brass	None	Brass	65	65	None
UL030AB27XF	CRI>80	IP68	Rotating and swivelling	40°	0.85W / 1.4W / 2W / 3W / 4.6W	2700K	129 - 515	Antique brass	None	Brass	65	65	None
UL030AB30XF	CRI>80	IP68	Rotating and swivelling	40°	0.85W / 1.4W / 2W / 3W / 4.6W	3000K	130 - 520	Antique brass	None	Brass	65	65	None

Accessories

Find the perfect product you are looking for.

Waterproof junction box

Gel filled waterproof junction box

2-core rubber cable
