Caiman Quick Connect

CCT switchable between 3000K, 4000K & 5700K
Wattage Switchable
IP66 for external use
Unique full length mounting slider allows complete freedom of mounting positions
Quick connect through-wired version for side entry to avoid opening the product
Versabox plug and play microwave sensor kit to automate lights off when no presence is detected
Rear and side housing conduit entry points
All installation points are marked on the outside of the luminaire to aid accurate pre-drilling, BESA mount accessory (ACBESA) sold separately
Supplied with mounting clips, hanging bracket and compression glands at either end of luminaire
ACKITMWS must be assembled by Collingwood Production only.

Wattage / Lumens

Code	CRI	IP Rating	Sensor Option	Body Material	Beam Angle	Wattage Range	CCT Range	Lumens Range	Width	Length	Dimmable Option	Emergency Option	Colour / Finish
AC4TWN	CRI>80	IP66	None	PC	120°	18-37W	3000K / 4000K / 5700K	2590-5500	95	1,200	None	None	Grey
AC5TWN	CRI>80	IP66	None	PC	120°	28-56W	3000K / 4000K / 5700K	3920-8400	95	1,500	None	None	Grey
AC6TWN	CRI>80	IP66	None	PC	120°	33 67W	3000K / 4000K / 5700K	4690-10050	95	1,800	None	None	Grey
